ONE MAN SCISSOR LIFT equipment is an extremely light and flexible lift equipment. This device really took the world by storm. Whether it is a factory building or a personal home, it is an excellent choice in the elevator industry equipment. When we designed this equipment, we adopted many top-level advanced designs. For example, we specially equipped the ONE MAN SCISSOR LIFT equipment with the function of single-person loading. What is the single-person loading function? The single-person loading function means that a worker can easily load the ONE MAN SCISSOR LIFT equipment onto the pickup truck. This is a very convenient function. Why do you say that? Since large aerial work equipment is usually not required for some lower height aerial work, it is the best choice to choose our ONE MAN SCISSOR LIFT equipment, but how to transport it to the work site? The functionality of our one-person loaders is designed for this reason. As long as you have another pickup truck we can put it on, and it only takes one person. Because the weight we designed for the ONE MAN SCISSOR LIFT equipment is low, it can be lifted and loaded onto a pickup truck by one person. In addition, in order to adapt to work in some working places without power supply, we also equipped him with a battery-powered option, so that in some places where it is inconvenient to obtain AC power, we can continue to use battery power for lifting work. In addition, we also have a lot of safety configurations. For example, the most important design is that when the outrigger is not opened, the ONE MAN SCISSOR LIFT device cannot work, because we have installed a safety sensor at the position where the outrigger is inserted. , When the outrigger is not inserted, the central control lock is not opened, so the lifting work cannot be carried out. If you also need such a lightweight device, contact us! Mobile Aluminum Work Platform, Cargo Lifter, Scissor Lift Design,
Chinese Professional Lift Boom - China Articulated Towable Boom Lift Daxlifter – Daxin Detail:

The towable boom lift is one of our main products.Towable boom lift has a high ascent height, a large operating range, and the arm can be folded over obstacles in the sky.Max Platform height can reach 16m with 200kg capacity.

Model Type

DXBL-10A

DXBL-12A

DXBL-14A

DXBL-16A

Lifting height

10M

12M

14M

16M

Working height

12M

14M

16M

18M

Load capacity

200KG

Platform size

0.9*0.7M

Working radius

5M

6.5M

8M

10.5M

Net Weight

1855KG

2050KG

2500KG

2800KG

Overall Size( L*W*H)

6.65*1.6*2.05M

7.75*1.7*2.2M

6.5*1.7*2.2M

7*1.7*2.2M

Supporting Legs Stride Distance (Horizontal)

3.0 M

3.6 M

3.6 M

3.9 M

Supporting Legs Stride Distance (Vertical)

4.7 M

4.7 M

4.7 M

4.9 M

Wind Resistance Level

Less than 5

20’/40’ Container Loading Quantity

20’/1set

40’/2sets

20’/1set

40’/2sets

40’/1set

40’/2sets

40’/1set

40’/2sets

As a reminder, you need to clear or replace the hydarulic oil. Waterproof design for electric parts, pump station, DC motor and so on. Maintaince Hole: Convenient for daily maintaince, Self Leveling Sole, Tilt Angle Sensor: once the body incline more than 3°,it can’t lift and only can low down to guarantee safety. Waterproof control panel and Electric Box, Controal panel equipped with main switch:operator must control main switch and function rod together to avoid unconscious operation. Besides,our self propelled boom lift also own many advantages,

1 With automatic walking function, it can walk fast and slowly under different working conditions. Only one person can operate the machine to continuously complete lifting, forwarding, backing, turning, turning and other actions when working at heights, which is more traditional than traditional hydraulic platforms. Greatly improve work efficiency, reduce the number of operators and labor intensity.

  2 All actions are controlled by the operating handle on the workbench. The motor is continuously variable, which effectively prolongs the service life of the battery and the motor. The motor only consumes energy during work. With multi-motor structure, walking and lifting are respectively completed by different motors. When the boom is in any position, the working platform can walk safely, and the walking speed decreases with the increase of the lifting height.

  3 It adopts reverse current brake and mechanical parking brake, which is easy to operate, safe and reliable. The service brake is automatically compensated and the brake is disc brake.

  4 The intelligent charging system adopts a fully automatic charger, which can automatically complete the entire charging process. When the battery is fully charged, it will automatically stop charging.

  5 large-angle steering system, making the machine has excellent flexibility. With hydraulic automatic steering function. The platform is driven by two AC variable frequency motors.

6 Control system

● Using PLC and CAN bus control methods, an industrial controller is installed on the chassis, turntable and platform respectively, which simplifies the circuit and facilitates maintenance and repair. The metal anti-air plug is adopted, and the protection level reaches IP65. At the same time, it adopts advanced CAN bus control, simple circuit, good reliability, simple maintenance and fault diagnosis.

● There are upper and lower consoles (ground console and platform console), and the upper and lower consoles are converted by reversing switches. The upper control is used to lock the lower console.

● The lower console has an hour meter and displays the remaining battery power for instructions.

● There is a foot switch on the platform, which can only be operated by stepping on the foot switch.

● Both the upper and lower consoles are equipped with emergency stop buttons. When an unexpected operation occurs, the operator can quickly cut off the power supply to prevent the platform from continuing to move.

 7 With self-diagnosis function, customers can quickly grasp the working status of the equipment in time and better maintain the equipment. At the same time, this product has the following functions:

●Hour meter

●Battery discharge indicator

●Light indicator

●Driver operation warning

  8 Security protection

● The working bucket has an automatic leveling function, and the inclination angle of the working bucket relative to the horizontal plane cannot be greater than 1.5°.

● When the platform amplitude and height reach a certain level, the driving speed and boom movement speed are automatically restricted. When the machine is parked on the ground where the unevenness exceeds 3°, the boom movement will be restricted.

● The upper and lower consoles are protected by protective covers.

● There are dust and sand prevention devices at the head of the boom and the piston rod of the cylinder.

● There are rings on the bottom frame and turntable for easy hoisting.

● The logo is clear and the meaning is clear.

1
2
3


Product detail pictures:

Chinese Professional Lift Boom - China Articulated Towable Boom Lift Daxlifter – Daxin detail pictures

Chinese Professional Lift Boom - China Articulated Towable Boom Lift Daxlifter – Daxin detail pictures

Chinese Professional Lift Boom - China Articulated Towable Boom Lift Daxlifter – Daxin detail pictures

Chinese Professional Lift Boom - China Articulated Towable Boom Lift Daxlifter – Daxin detail pictures

Chinese Professional Lift Boom - China Articulated Towable Boom Lift Daxlifter – Daxin detail pictures

Chinese Professional Lift Boom - China Articulated Towable Boom Lift Daxlifter – Daxin detail pictures


Related Product Guide:

Towable man lift is an aerial work product that sells well all over the world. The mast-type lifting structure and the high-quality material of aluminum alloy are undoubtedly a high-quality and high-performance product. From our company's sales data for many years, it can be concluded that the sales volume of towable man lift products can account for 30% of all products, and there are many reasons for the large sales volume. Compared with the scissor-type lifting platform, the mast-type design structure is more space-saving and occupies a smaller area, which is more suitable for indoor venues. And towable man lift has the function of single-person loading, with a pull-out handle at the bottom and wheels installed on the side of the device, so that it can be easily loaded onto the truck even when one person is working. This design function allows small electric man lift to be easily transported to different workplaces. Even if you don't have a forklift, you only use a truck and a staff member. You can also use this function to load and unload independently without delaying work. The height of its platform has many options, from a low height of 4.7m to a high height of 12m. The space is very selective and can meet the work needs of many people. Chinese Professional Lift Boom - China Articulated Towable Boom Lift Daxlifter – Daxin , The product will supply to all over the world, such as: Albania, moldova, Slovenia,
